HD 500 Endoscopy System
High-definition endoscopy system for clear and efficient clinical imaging.
Installation & commissioningAfter-sales supportAMC / service
Overview
High-definition endoscopy system for clear and efficient clinical imaging.
Features
HD-500 image processor with VLS-50D 2-LED light source (white LED 70 W, violet LED 50 W)
VIST chromoendoscopy for better contrast of mucosa and blood vessels at the touch of a button
Bright far-field images in both white-light and VIST modes
Built-in workstation with 500 GB storage, DICOM, patient database and report printing — no external software needed
500 series CMOS scopes with multi-stage colour, edge and structure enhancement
Ergonomic scope handle, short bending radius and gradual stiffness for smoother insertion
Water-jet on every scope; large instrument channels for therapeutic work
LED light source rated for 10,000+ hours — lower maintenance cost
Specifications
HD-500 Image Processor
| Video output | SDI, DVI, VGA, CVBS, S-video |
|---|---|
| Resolution | 960p |
| Digital zoom | 1.4×, 1.6×, 1.8× |
| Patient data | ≥ 10,000 records |
| IRIS | Peak / Average / Auto |
| Colour adjustment | Red, blue, chroma, ±15 levels |
| Air feeding | 4 levels (Off / L / M / H) |
| AGC | Yes |
| Data management | 500 GB built-in, 4 × USB, DICOM |
| White balance | Auto-saved |
| Image enhancement | Structure and edge enhancement |
| Contrast / denoise | L / M / H, auto-denoise |
| Dimensions | 480 × 370 × 125 mm |
VLS-50D Light Source
| Main lamp | White LED 70 W, violet LED 50 W |
|---|---|
| White-light mode | High colour rendering and luminous flux |
| VIST chromoendoscopy | Versatile Intelligent Staining Technology |
| Brightness | Auto / manual, 1 – 19 levels |
| Transillumination | 6 – 8 seconds |
| Service life | 10,000 hours (continuous use) |
| Hot plugging | Yes |
| Dimensions | 473 × 370 × 154 mm |
500 Series Scopes
| Parameter | EG-500 | EG-500L | EC-500 | EC-500T | EC-500L | EC-500L/T |
|---|---|---|---|---|---|---|
| Type | Gastroscope | Gastroscope | Colonoscope | Colonoscope | Colonoscope | Colonoscope |
| Field of view | 140° | |||||
| Depth of view | 3 – 100 mm | |||||
| Distal-end diameter | 9.3 mm | 9.8 mm | 12 mm | 12 mm | 12.9 mm | 12.9 mm |
| Insertion diameter | 9.3 mm | 9.8 mm | 12.5 mm | 12.5 mm | 12.9 mm | 12.9 mm |
| Instrument channel | 2.8 mm | 3.2 mm | 3.8 mm | 3.8 mm | 4.2 mm | 4.2 mm |
| Angulation | U 210°, D 90°, L/R 100° | U 210°, D 90°, L/R 100° | U/D 180°, L/R 160° | U/D 180°, L/R 160° | U/D 180°, L/R 160° | U/D 180°, L/R 160° |
| Working length | 1050 mm | 1050 mm | 1350 mm | 1700 mm | 1350 mm | 1700 mm |
| Water-jet | Yes | |||||
Specifications are for reference only and may change without notice.
Applications
Gastroenterologydiagnostictherapeutic endoscopy
System Components
Processor, light source, monitor and compatible endoscopes.
Accessories
Endoscopes, cables, footswitch, trolley and other compatible accessories.
