X-2600 Laparoscopy System (SonoScape)

Complete laparoscopic imaging solution designed for minimally invasive surgery.

Download Brochure
Installation & commissioningAfter-sales supportAMC / service
Overview
Complete laparoscopic imaging solution designed for minimally invasive surgery.
Features
Integrated HD video system centre compatible with flexible, rigid and fibre scopes
Automatically identifies the connected scope type and switches to the matching interface
2-LED light source rated for 50,000+ hours — brighter images with minimal light loss
Full HD 1080p output with up to 4× digital zoom
SFI / VIST chromoendoscopy and CHb haemoglobin enhancement
8" touch screen with tactile control panel and one-tap screen lock
Four lightweight camera heads with universal coupling for rigid and fibre scopes
X20 series flexible scopes for gastroenterology, pulmonology, urology and surgery
Picture-by-picture (PBP), one-step connection and hot plugging
Specifications
X-2600 Integrated Endoscopy Video System Centre
Video output1080p, 2 × DVI, 2 × SDI
Light source2-LED, ≥ 50,000 hours
User interface8" touch screen
StoragePicture / video recording to portable USB memory
Digital zoomUp to 4.0×
White balanceAuto & memory
Brightness adjustmentAutomatic gain control; auto / manual 1 – 19 levels
IRISPeak / Average / Auto (flexible); full / wide / circular screen (rigid)
Transillumination6 – 8 seconds
CHb haemoglobin enhancementYes
Picture by picture (PBP)Yes
One-step connection / hot pluggingYes / Yes
Power100 – 240 V AC, 50/60 Hz, 350 VA
Dimensions / weight492 × 373.5 × 205 mm / 16.7 kg
Camera Heads
Lens mountUniversal coupling
Pickup systemCMOS image sensor
10.110.201Focal lens 19 – 38 mm, up to 2.0×
10.111.201Focal lens 18 mm
10.112.201Focal lens 32 mm
10.100.201Focal lens 18 mm
Electric-shock protectionType BF
Liquid protectionIPX7
X20 Series Flexible Scopes
ParameterEG-X20EC-X20EC-X20LEB-X20TEB-X20ECY-X20
SpecialityGastroenterologyGastroenterologyGastroenterologyPulmonologyPulmonologySurgical
Field of view145°145°145°120°120°120°
Depth of field2 – 100 mm2 – 100 mm2 – 100 mm2 – 100 mm2 – 100 mm3 – 50 mm
Distal-end diameter9.3 mm12 mm12 mm5.9 mm4.9 mm2.7 mm
Insertion diameter9.3 mm12.5 mm12.5 mm5.9 mm4.9 mm5.5 mm
Instrument channel2.8 mm3.8 mm3.8 mm2.8 mm2.0 mm2.2 mm
AngulationU/D 210/120°, L/R 100/100°U/D 180/180°, L/R 160/160°U/D 180/180°, L/R 160/160°U/D 180/130°U/D 180/130°U/D 220/130°
Working length1050 mm1350 mm1700 mm600 mm600 mm380 mm
Specifications are for reference only and may change without notice.
Applications
General SurgeryGynecologyUrologyGastrointestinal Surgery
System Components
Camera, processor, light source, monitor and related equipment.
Accessories
Laparoscopic scopes, cables, trolley and compatible accessories.
